Netgate 2100 BASE pfSense+ Security Gateway

The Netgate® 2100 Security Gateway Appliance with pfSense® Plus software offers unmatched performance and flexibility in its class. It is ideal for home use, remote work, and small businesses that need more computing resources to utilise multiple pfSense® add-on packages and VPN performance for multiple users and site-to-site connections. Equipped with a dual-core ARM Cortex A53 1.2 GHz CPU, a dedicated 1 GbE WAN port (RJ45/SFP combo), (4) 1 GbE Marvell switch ports, 4 GB DDR4 RAM and expandable storage. The 2100 has additional expansion slots for DIY LTE, Wi-Fi or M.2 SSD expansion.

The Netgate 2100 is a compact and powerful desktop device. Equipped with a 1.2 GHz dual-core ARM Cortex A53 processor and 4 GB DDR4 RAM, it can be used as a 2.20 Gbit/s router, 964 Mbit/s firewall or 254 Mbit/s IPsec VPN solution.

Technical data

• CPU: Marvell Armada 3720 (88F3720) ARMv8-A 64-bit Cortex A53 @ 1.2GHz with NEON SIMD and FPU
• CPU Cores: Dual Core
• Network Interfaces: 1 x 1 Gigabit Ethernet WAN port (RJ45 / SFP Combo)
  4 x 1 Gigabit Ethernet LAN ports (Marvel 88E6141 switch)
  LAN ports can be repurposed for additional WAN ports
• Storage: 8 GB eMMC (upgradable)
• Memory: 4 GB DDR4 (not expandable)
• Expansion: 1 x M.2 ‘B’ key sockets (SSD, LTE) 1x miniPCIe (WiFi) microSIM slot
• Misc: MiniUSB (console cable included)
• USB: 1 x 2.0 port
• LED: 3 x full color RGB LEDs
• Enclosure: Desktop 42.2 mm (1.7″) tall x 108 mm (4.25″) deep x 172.7 mm (6.8″) wide with integrated keyholes for wall mount
• Cooling: Passive
• Power: External ITE P/S AC/DC 100-240V, 50-60 Hz, 12V 2.0A, threaded barrel connector
  AC Inlet: IEC320-C7 (2 PIN)
  One US, UK, EU or ANZ power cord included
  US Power Cord: NEMA 1-15P to IEC320-C7
  UK Power Cord: BS 1363 to IEC320-C7
  EU Power Cord: CEE7/16 to IEC320-C7
  ANZ Power Cord: AS 3112 (ungrounded) to IEC320-C7
• Operating Temperature: 0°C (32°F) to 50°C (122°F)
• Certifications: CE, FCC (Class B), RoHS, UL, RCM, VCCI, UKCA
• Mounting: with integrated keyholes for wall mount

Erfahren Sie mehr über diese Appliance auf der offiziellen Netgate-Website.

Software

pfSense Plus software offers the performance, flexibility, reliability and business assurance you expect from leading secure networking applications:

• Flexible options for third-party applications
• Proven management mechanisms
• Proven reliability
• Full support for business assurance

At a fraction of the cost of proprietary alternatives, pfSense Plus software is the perfect solution. Popular use cases for pfSense Plus include load balancing, traffic shaping, captive portal, UTM device, DNS/DHCP server, IDS/IPS, failover WAN and many more.

We are happy to provide you with a customised quote for larger orders! Please send your enquiry to sales@qwertiko.de.
